Intel S2600stbr Server Motherboard, Dual 3647, C624, 16xdimm, 2x10gbe, Pcie X16, Ssi Eeb
no surcharge fee
Paypal/MasterCard/Visa/Amex
$1,707
SKU
S2600STBR
SKU#: S2600STBR / ITEM NO: 986000 / BRAND: Intel
$1,707.00
Shipping Calculator:
Loading...
Compatible Product Series
2nd Generation Intel® Xeon® Scalable Processors
Supported Operating Systems
Windows Server 2019*, Windows Server 2016*, Red Hat Enterprise Linux 7.6*, Red Hat Enterprise Linux 7.5*, SUSE Linux Enterprise Server 15*, SUSE Linux Enterprise Server 12 SP4*, Ubuntu*, VMware*
Board Form Factor
SSI EEB (12 x 13 in)
Chassis Form Factor
Rack or Pedestal
Socket
Socket P
Integrated Systems Available
No
Integrated BMC with IPMI
IPMI 2.0 & Redfish
Rack-Friendly Board
Yes
TDP
205 W
Included Items
(1) Intel® Server Board S2600STBR
(2) SATA cables 880.00mm
(1) IO shield
(1) Protective insulator
(1) Configuration label (sticker to be added to chassis)
Board Chipset
Intel® C624 Chipset
Target Market
Small and Medium Business
Off Roadmap
No
Supplemental Information
Embedded Options Available
No
Datasheet
View now
Description
A standard form factor server board supporting two 2nd Generation Intel® Xeon® Scalable Processors, up to 205 W TDP, 16 DIMMs, and Dual 10GBase-T ports.
Additional Information URL
View now
Memory Specifications
Max Memory Size (dependent on memory type)
2 TB
Memory Types
DDR4 ECC RDIMM/LRDIMM 2133/2400/2666/2933
Max # of Memory Channels
16
Max # of DIMMs
16
ECC Memory Supported ‡
Yes
Processor Graphics
Integrated Graphics ‡
No
Graphics Output
VGA
Expansion Options
Max # of PCI Express Lanes
96
PCI Express Revision
3.0
PCIe x8 Gen 3
3
PCIe x16 Gen 3
3
PCIe OCuLink Connectors (NVMe support)
4
I/O Specifications
# of USB Ports
7
USB Revision
2.0 & 3.0
Total # of SATA Ports
12
RAID Configuration
SW RAID 0/1/10 (5 optional)
# of Serial Ports
1
# of LAN Ports
2
Integrated LAN
(Optional) two 10 Gb SFP+ connectors
Package Specifications
Max CPU Configuration
2
Advanced Technologies
Intel® Optane™ Memory Supported ‡
No
Picture shown is for illustration purpose only
Please refer to Manufacturer SKU for the exact details
