Ivsec Speed Dome 4mp 60fps 2.8-12mm Lens Motorisedip66 Ptz Full Colour Adv Ivs
Delivery
Overview
CCTV Storage Calculator https//www.seagate.com/au/en/video-storage-calculator/
NC550ADX Security Camera
PTZ Pan Tilt and Zoom camera with motorised 2.8-12mm lens enabling more control via the mobile app or set it on a pre-set patrol. Full colour at night. Improvements made to the image sensor -1/1.8 enlarged image sensor enables more light to be gathered. Together with built-in warm-light LEDS this creates an excellent full colour image. Experience technological leaps in AI analytics/intelligent video implemented in this camera such as face and licence plate recognition.
| Camera Type | Dome |
| Image Sensor | 1/1.8″ Progressive CMOS |
| Maximum Video Resolution Megapixels | 4 |
| Maximum Video Resolution | 2560 x 1440 |
| Lens | 2.8-12 mm H.FOV 114.6 to 48.3° |
| Lens Type | Motorised Zoom |
| Maximum Night IR Distance M | 20 |
| Video Compression | H.265 H.265 H.264 H.264 MJPEG |
| ONVIF depends on firmware version | ONVIF Profile S/G/T 21.12 or greater Http API |
| IP Rating | IP66 |
| Operating Environment | -35ºC to 60ºC 31ºF-140ºF Humidity 20-95 RH |
| Dimensions | Ø153 X 118.8mm |
| Weight Net | 0.95 |
| Accessories | – |
| Power Supply | Power over Ethernet IEEE 802.3af DC12V |
| Power Consumption | <14W |
| Connectors | RJ-45 DC Power Input Reset Button |
| Outdoor Use | Yes |
| Vandal Resistant | Yes |
| Frame Rate at Resolution | 50 |
| Day/Night Mode | Schedule Time Based Full colour white LEDS or Day/Night IR LEDS |
| LED Types | IR Warm White |
| Image Enhancement | SMART IR Flip mode Brightness Contrast Saturation Sharpness Hue Mirror Angle Flip Corridor Mode Back Light White Balance Shutter Time Exposure Defog 3D Noise Reduction |
| Edge Recording microSD/SDHC Card | Micro SD/SDHC Card |
| Multiple Streams encode format | 3 Streams |
| Audio Streaming | Two-way audio microphone with a distance up to 8m and speaker included |
| Protocols | TCP/IP UDP HTTP HTTPS DHCP FTP RTP/RTSP DNS DDNS NTP PPPOE UPNP SMTP SNMP P2P QR code |
| Intelligent Video IVS | Face Recognition Licence Plate Recognition Perimeter Intrusion Detection Face Recognition Human & Vehicle Detection Line Crossing Detection Stationary Object Detection Crossing Counting Heat Map Crowd Density Detection Queue Length Detection License Plate Detection Rare sound detection |
| Cloud option camera only | Dropbox |
| Software | Device Search/Config Tool Surveillance Client CMS/VMS Mobile app QR code |
| Power Over Ethernet | Yes |
| Ethernet | Ethernet 10/100 Base-T |
| In The Box | Free Software available ivsecurity.com.au/support/software Printed quick user guide installation template mounting screws and plugs |
| Warranty | 3 Year Warranty |
CCTV Storage Calculator https//www.seagate.com/au/en/video-storage-calculator/
NC550ADX Security Camera
PTZ Pan Tilt and Zoom camera with motorised 2.8-12mm lens enabling more control via the mobile app or set it on a pre-set patrol. Full colour at night. Improvements made to the image sensor -1/1.8 enlarged image sensor enables more light to be gathered. Together with built-in warm-light LEDS this creates an excellent full colour image. Experience technological leaps in AI analytics/intelligent video implemented in this camera such as face and licence plate recognition.
| Camera Type | Dome |
| Image Sensor | 1/1.8″ Progressive CMOS |
| Maximum Video Resolution Megapixels | 4 |
| Maximum Video Resolution | 2560 x 1440 |
| Lens | 2.8-12 mm H.FOV 114.6 to 48.3° |
| Lens Type | Motorised Zoom |
| Maximum Night IR Distance M | 20 |
| Video Compression | H.265 H.265 H.264 H.264 MJPEG |
| ONVIF depends on firmware version | ONVIF Profile S/G/T 21.12 or greater Http API |
| IP Rating | IP66 |
| Operating Environment | -35ºC to 60ºC 31ºF-140ºF Humidity 20-95 RH |
| Dimensions | Ø153 X 118.8mm |
| Weight Net | 0.95 |
| Accessories | – |
| Power Supply | Power over Ethernet IEEE 802.3af DC12V |
| Power Consumption | <14W |
| Connectors | RJ-45 DC Power Input Reset Button |
| Outdoor Use | Yes |
| Vandal Resistant | Yes |
| Frame Rate at Resolution | 50 |
| Day/Night Mode | Schedule Time Based Full colour white LEDS or Day/Night IR LEDS |
| LED Types | IR Warm White |
| Image Enhancement | SMART IR Flip mode Brightness Contrast Saturation Sharpness Hue Mirror Angle Flip Corridor Mode Back Light White Balance Shutter Time Exposure Defog 3D Noise Reduction |
| Edge Recording microSD/SDHC Card | Micro SD/SDHC Card |
| Multiple Streams encode format | 3 Streams |
| Audio Streaming | Two-way audio microphone with a distance up to 8m and speaker included |
| Protocols | TCP/IP UDP HTTP HTTPS DHCP FTP RTP/RTSP DNS DDNS NTP PPPOE UPNP SMTP SNMP P2P QR code |
| Intelligent Video IVS | Face Recognition Licence Plate Recognition Perimeter Intrusion Detection Face Recognition Human & Vehicle Detection Line Crossing Detection Stationary Object Detection Crossing Counting Heat Map Crowd Density Detection Queue Length Detection License Plate Detection Rare sound detection |
| Cloud option camera only | Dropbox |
| Software | Device Search/Config Tool Surveillance Client CMS/VMS Mobile app QR code |
| Power Over Ethernet | Yes |
| Ethernet | Ethernet 10/100 Base-T |
| In The Box | Free Software available ivsecurity.com.au/support/software Printed quick user guide installation template mounting screws and plugs |
| Warranty | 3 Year Warranty |
Picture shown is for illustration purpose only
Please refer to Manufacturer SKU for the exact details
