Buy Seasonic VERTEX PX-1200W Power Supply, 80PLUS Platinum, Fully Modular, 135mm FDB Fan

Seasonic VERTEX PX-1200W Power Supply, 80PLUS Platinum, Fully Modular, 135mm FDB Fan

Delivery

In Stock

Usually ships within 24 hours*

Click to call action

no surcharge fee

Paypal/MasterCard/Visa/Amex

$482

Our Best Price

482 482 AUD 100

SKU

PX-1200

SKU#: PX-1200 / ITEM NO: 970514 / BRAND: Seasonic

$482.00

Shipping Calculator:

Add to Wish List Add to Compare

Overview

FEATURE SUMMARY
Super-High Efficiency, 80 PLUS® Platinum Certified

Fully Modular

ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)

Top-Quality 135 mm Fluid Dynamic Bearing Fan

Premium Hybrid Fan Control

Tight Voltage Regulation (12V, 5V and 3.3V) [± 3%]

Gold Plated High Current Terminal (MB, CPU and PCIe)

Technical Specifications
80PLUS® Platinum
Cybenetics Efficiency Level TBA
Cybenetics Noise Level TBA
Form Factor Intel ATX 12V
Dimensions 160 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size 135 mm
Fan Control Premium Hybrid Fan Control
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 10 Years

Power Output
AC Input Voltage: 100 V - 240 V
Current: 15 - 7.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 100 A 0.3 A 3 A
125 W 1200 W 3.6 W 15 W
Total Continuous Power 1200 W

Power Output
AC Input	Voltage: 100 V - 240 V
Current: 15 - 7.5 A
Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
Maximum Power	25 A	25 A	100 A	0.3 A	3 A
125 W	1200 W	3.6 W	15 W
Total Continuous Power	1200 W

FEATURE SUMMARY

Super-High Efficiency, 80 PLUS® Platinum Certified

Fully Modular

ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)

Top-Quality 135 mm Fluid Dynamic Bearing Fan

Premium Hybrid Fan Control

Tight Voltage Regulation (12V, 5V and 3.3V) [± 3%]

Gold Plated High Current Terminal (MB, CPU and PCIe)

Technical Specifications
80PLUS®		Platinum
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12V
Dimensions		160 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	135 mm
	Fan Control	Premium Hybrid Fan Control
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Fully Modular
Cable Information	Cable type	Flat black cables
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF @ 25 °C, excl. fan	150,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		10 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 15 - 7.5 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	25 A	25 A	100 A	0.3 A	3 A
	Maximum Power	125 W		1200 W	3.6 W	15 W
	Total Continuous Power	1200 W
