Picture shown is for illustration purpose only
Please refer to Manufacturer SKU for the exact details
Customer Also Bought
Customer Also Viewed
Product Overview
The MSAT2SAT3 mSATA to SATA adapter enables you to connect a standard SATA drive to an available mSATA port.
The adapter improves system capacity by enabling an mSATA port to host a larger SATA hard drive (tested up to 4TB). For guaranteed compatibility and performance the adapter is compliant with SATA I/II/III revisions, allowing for transfer speeds up to 6Gb per second.
The MSAT2SAT3 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Specifications
|
Warranty Information |
|
|---|---|
|
Warranty |
2 Years |
|
Physical Characteristics |
|
|
Product Height |
0.3 in [8 mm] |
|
Product Length |
2 in [51 mm] |
|
Product Weight |
0.1 oz [4 g] |
|
Product Width |
1.2 in [30 mm] |
|
Hardware |
|
|
Compatible Drive Types (Type and Rate) |
SATA |
|
Drive Installation |
Fixed |
|
Drive Size |
2.5in & 3.5in |
|
Interface |
Micro SATA |
|
|
SATA |
|
Number of Drives |
1 |
|
Performance |
|
|
Max Drive Capacity |
Currently tested with up to 4TB 7200 RPM hard drive |
|
Type and Rate |
SATA III (6 Gbps) |
|
Connector(s) |
|
|
Drive Connectors |
1 - SATA (7 pin; Data) Receptacle |
|
Host Connectors |
1 - mSATA (52 pin; Mini SATA) Male |
|
Environmental |
|
|
Humidity |
Operating 20% to 80% Non Operating 15% to 90% |
|
Operating Temperature |
5°C to 50°C (41°F to 122°F) |
|
Storage Temperature |
-25°C to 70°C (-13°F to 158°F) |
|
Packaging Information |
|
|
Shipping (Package) Weight |
0 lb [0 kg] |
|
What's in the Box |
|
|
Included in Package |
1 - mSATA to SATA Adapter |
|
|
1 - Screw kit |
|
|
1 - Installation Guide |
