• EAP Controller Software enables administrators to easily manage hundreds of EAPs
• Cluster management makes it easy to manage a small network by allowing up to 24 Auranet EAP115 units to act as a single cluster
• Supports IEEE 802.3af PoE for convenient and affordable installation
• Simple mounting design for easy attachment to a wall or ceiling
• 300Mbps wireless data rate for uninterrupted wireless connection
• Captive portal provides one convenient method of authentication for Wi-Fi guests
• Rate limit per SSID to restrict the bandwidth of each client
• Access Control restricts sets limitations for client access to the specified network segment
• Reboot Schedule enables all APs to automatically reboot within a specified time
• WPA/WPA2-enterprise, 802.1X with RADIUS secure authentication and rogue access point detection ensure the security of WLAN network
• Multi-SSID divides multiple wireless network for different user types
• Load balance ensures large business networks with smooth a network experience
• Compatible with 802.11 b/g/n products
• QoS function prioritizes data, voice, and video to ensure time-sensitive applications take priority over all other traffic
• Durable housing prevents dust from dropping onto the PCB through bypass louver to provide long-term, unhindered operation
• Adopts Low Smoke Zero Halogen (LSOH) materials for UL2043 compliance

HARDWARE FEATURES

• Interface: Fast Ethernet (RJ-45) Port *1(Support IEEE802.3af PoE)
• Button: Reset
• Power Supply: PoE or external 12VDC/1.0A power supply
• Power Consumption: 5W
• Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Dimensions (W x D x H): 7.1 x 7.1 x 1.9 in. (180*180*47.5mm)
• Antenna Type: Internal 2* 3dBi Omni
• Mounting: Ceiling /Wall Mounting (Kits included)
• Physical Security Lock: Kensington Lock Slot
• Watch Dog: Yes

WIRELESS FEATURES

• Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Frequency: 2.4-2.4835GHz
• Signal Rate:
  • 11n: Up to 300Mbps(dynamic)
  • 11g: Up to 54Mbps(dynamic)
  • 11b: Up to 11Mbps(dynamic)
• Reception Sensitivity:
  • 300M: -71dBm@10% PER
  • 150M: -75dBm@10% PER
  • 54M: -78dBm@10% PER
  • 11M: -93dBm@8% PER
  • 6M: -92dBm@10% PER
  • 1M: -96dBm@8% PER
• Wireless Functions:
  • Multiple SSIDs (Up to 8 SSIDs)
  • Enable/Disable Wireless Radio
  • Automatic Channel Assignment
  • Transmit Power Control (Adjust Transmit Power on dBm)
  • QoS(WMM)
  • Rate Limit
  • Reboot Schedule
  • Wireless Schedule
  • Wireless Statistics based on SSID/AP/Client
• Wireless Security:
  • Captive Portal Authentication
  • Access Control
  • Wireless Mac Address Filtering
  • Wireless Isolation Between Clients
  • SSID to VLAN Mapping
  • Rogue AP Detection
  • 802.1X Support
  • 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK
• Transmission Power
  • CE:
  • <20dBm
  • FCC:
  • <26dBm

MANAGEMENT

• Auranet Controller Software: Yes
• Cluster Mode: Yes
• Email Alerts: Yes
• LED ON/OFF Control: Yes
• Management MAC Access Control: Yes
• SNMP: v1,v2c
• System Logging Local/Remote Syslog: Local/Remote Syslog
• Telnet: Yes
• Web-based Management: HTTP/HTTPS

OTHERS

• Certification: CE, FCC, RoHS
• Package Contents
  • 300Mbps Wireless N Ceiling Mount Access Point EAP115
  • Power Adapter
  • Mounting Kits,
  • Installation Guide
• System Requirements: Microsoft Windows 10/8/7/Vista/XP
• Environment
  • Operating Temperature: 0?~40? (32?~104?)
  • Storage Temperature: -40?~70? (-40?~158?)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
